Surface 7th Edition

Technical Specifications

• Summary: Microsoft Surface Laptop 7 . Product type: Laptop, Form factor: Clamshell. Processor family: Intel Core Ultra 7, Processor model: 266V. Display diagonal: 38.1 cm (15"), Display resolution: 2496 x 1664 pixels, Touchscreen. Internal memory: 16 GB, Internal memory type: LPDDR5x-SDRAM. Total storage capacity: 256 GB, Storage media: SSD. On-board graphics card model: Intel Arc Graphics 140V. Operating system installed: Windows 11 Pro. Product colour: Black. Weight: 1.66 kg
• Vendor Homepage: https://www.microsoft.com/en-us/surface/business/surface-laptop-intel-7th-edition
• Name: NB SURFACE7 CU7-266V 15"T/16/256GB EP2-22757 MICROSOFT
• Category Code: NB
• NB Family name: Surface
• Model name: 7th Edition
• Processor manufacturer: Intel
• Processor family: Intel Core Ultra 7
• Processor generation: Intel Core Ultra (Series 2)
• Processor model: 266V
• Processor cores: 8
• Processor threads: 8
• Performance cores: 4
• Low Power Efficient-cores: 4
• Performance-core Max Turbo Frequency: 5
• Low Power Efficient-core Max Turbo Frequency: 3.7
• Performance-core base frequency: 2.2
• Efficient-core base frequency: 2.2
• Processor cache: 12
• Processor cache type: Smart Cache
• Maximum turbo power: 37
• Processor base power: 17
• Display diagonal: 15
• Display resolution: 2496 x 1664
• Touchscreen: Yes
• Display technology marketing name: PixelSense Flow
• LED backlight: Yes
• Native aspect ratio: 3:2
• Display glass type: Gorilla Glass
• Maximum display brightness (HDR): 600
• Pixel density: 201
• RGB colour space: sRGB
• Maximum refresh rate: 120
• Contrast ratio (typical): 1300:1
• High Dynamic Range (HDR) supported: Yes
• High Dynamic Range (HDR) technology: Dolby Vision IQ
• Product type: Laptop
• Product colour: Black
• Form factor: Clamshell
• Housing material: Aluminium
• Market positioning: Business
• Introduction year: 2025
• Copilot+ PC: Yes
• Neural processor unit (NPU): Intel AI Boost
• Sparsity support: Yes
• Windows Studio effects support: Yes
• AI software frameworks supported by NPU: DirectML/ONNX RT/OpenVINO/Windows ML
• Total processor performance up to: 118
• NPU performance up to: 48
• GPU performance up to: 66
• Internal memory: 16
• Internal memory type: LPDDR5x-SDRAM
• Maximum internal memory: 16
• Total storage capacity: 256
• Storage media: SSD
• Total SSDs capacity: 256
• Number of SSDs installed: 1
• SSD capacity: 256
• Card reader integrated: Yes
• Compatible memory cards: MicroSD (TransFlash)/MicroSDHC/MicroSDXC
• On-board GPU manufacturer: Intel
• On-board graphics card: Yes
• On-board graphics card family: Intel Arc Graphics
• On-board graphics card model: Intel Arc Graphics 140V
• On-board graphics card 4K support: Yes
• On-board graphics card 8K support: Yes
• Audio system: Dolby Atmos
• Speakers manufacturer: OmniSonic
• Built-in microphone: Yes
• Number of microphones: 2
• Front camera: Yes
• Front camera HD type: Full HD
• Front camera resolution: 1920 x 1080
• Top Wi-Fi standard: Wi-Fi 7 (802.11be)
• Wi-Fi standards: 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)
• Bluetooth: Yes
• Bluetooth Low Energy (BLE): Yes
• Bluetooth version: 5.4
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
• USB4 Gen 3x2 ports quantity: 2
• Intel Thunderbolt 4: Yes
• Combo headphone/mic port: Yes
• Charging port type: Surface Connect
• USB Type-C DisplayPort Alternate Mode: Yes
• Ambient light sensor: Yes
• Pointing device: Touchpad
• Keyboard backlit: Yes
• Island-style keyboard: Yes
• Keyboard layout: QWERTY
• Copilot key: Yes
• Operating system architecture: 64-bit
• Microsoft Copilot: Yes
• Pre-installed software: Microsoft 365 Apps
• Operating system installed: Windows 11 Pro
• Browsing time (Wi-Fi): 14
• Continuous video playback time: 22
• AC adapter power: 65
• USB Type-C charging port: Yes
• USB Power Delivery (USB PD): Yes
• Face recognition: Yes
• Windows Hello: Yes
• Trusted Platform Module (TPM): Yes
• Trusted Platform Module (TPM) version: 2.0
• Password protection: Yes
• Width: 329
• Depth: 239
• Height: 18.26
• Weight: 1660
• AC adapter included: Yes
• Units per Shipping Box: 1
• Unit Calculated Volume: 0.007866
• Unit Calculated Weight: 3
